Tennis Post - Fixed Type

MF-SP-TNS-A-FIX-A1
PRODUCT DESCRIPTION
Tennis Post – Fixed Type
Designed for durability and stable performance, this fixed type netball post provides a strong and reliable solution for schools, sports clubs, and recreational courts.
The fixed foundation sleeve mounting system ensures excellent stability during play. The integrated internal winch mechanism with gear assembly and locking system provides precise and secure net tensioning to the required ITF heights — 1,067 mm at posts and 914 mm at court centre.
All aluminium components are supplied with EN 10204 Type 3.1 Mill Test Certificates. All SS316 fasteners comply with ISO 3506 Grade A4-70.
Technical Data
Quick Specifications

Post Height Above FFL

1,070 mm

Net Height at Posts

1,067 mm

ITF Rule 1 — 42"

Net Height at Centre

914 mm

ITF Rule 1 — 36"

Post Diameter × Wall

100 mm OD × 3 mm

Net Dimensions

12,800 × 1,067 mm

Length × Depth

Net Mesh Size

40 – 45 mm

ITF Equipment Reg.

Net Tensile Strength

Min. 25 kN/m

EN 1510 Cl. 5.3

Net Tensile Strength

Min. 20 kN/m

EN 1509 Cl. 6.3

Net Tensioning

Internal Winch

Gear Assembly
& Locking System

Post Material

Al 6061-T6 / 6063-T5

EN 755-2

Governing Standard

EN 1510

ITF Rules of Tennis

Fasteners

SS316

ISO 3506 Grade A4-70
