Basketball Post - Fixed Type

MF-SP-BKB-FIX-A1
PRODUCT DESCRIPTION
Fixed Basketball Post
This fixed type basketball post is engineered for strength, long-term durability, and compliance with EN 1270:2006. Manufactured from heavy-duty mild steel, it provides a stable and reliable structure for outdoor and indoor sports facilities. The fixed foundation mounting ensures excellent stability during play while maintaining safety and consistent performance.
Designed specifically for outdoor public installations, the post incorporates a comprehensive safety padding system on all three hazard zones (post column, base plate, and backboard), UV-resistant tempered laminated glass backboard, and full hot-dip galvanizing with polyester powder coating for maximum corrosion resistance in exposed environments.
All steel components are hot-dip galvanized to ISO 1461 and powder coated to a minimum 60 microns DFT.
Technical Data
Quick Specifications

Overall Height

3050 mm

Overall Overhang

1600 mm

Backboard Width

1800 mm

Base Plate

300 x 300 x 25 mm

Glass Thickness

13.52mm

6+1.52PVB+6

Rim Diameter

490 mm

20mm Dia. Rod

Post Diameter

6" OD

Post Padding Height

FFL to 2000mm

Governing Standard

EN 1270:2006
